3M TEXTOOL DISCRETE SOCKETS
? ?
LASER DIODE SOCKETS
? COMPACT MINIATURE SOCKET SIZE FOR MAXIMUM BOARD DENSITY
? ACCOMMODATES MOST TO PACKAGE FORMATS WITH PIN CIRCLE
OPTIONS OF .079" (2.0 MM) OR .100" (2.54 MM), INCLUDING
POPULAR LASER DIODE DEVICES WITH .018” (0.46 MM) DIAMETER
LEADS
? THREE AND FOUR LEAD OPTIONS AVAILABLE
? FUNNELED ENTRY HOLES TO ASSIST LEAD INSERTION
PART NUMBER
203-6585-00-0602J
203-6585-50-0602J
203-6970-00-0602J
203-6970-50-0602J
204-6585-00-0602J
204-6585-50-0602J
204-6585-00-0602J
204-6970-50-0602J
CONTACT QTY.
3
3
3
3
4
4
4
4
PIN CIRCLE
.100 [ 2.54 ]
.100 [ 2.54 ]
.079 [ 2.0 ]
.079 [ 2.0 ]
.100 [ 2.54 ]
.100 [ 2.54 ]
.079 [ 2.0 ]
.079 [ 2.0 ]
MOUNTING FLANGE
YES
NO
YES
NO
YES
NO
YES
NO
POWER IN-LINE SOCKETS
? ACCEPTS A WIDE VARIETY OF IN-LINE DEVICES UP TO THREE LEADS
INCLUDING TO-220 WITH LEAD CROSS SECTIONS THAT ?T WITHIN A
DIAMETER RANGE OF .020”-.045” (0.51-1.14 MM)
? KELVIN CONTACTS
? BODY AND CONTACTS ARE REPAIRABLE
? TWO SLOTTED-OUT ENTRY PORTS ACCEPT DEVICES WITH .075"
(1.90 MM) TO .200" (5.1 MM) BETWEEN LEADS
? MUST BE MOUNTED TO BOARD WITH SCREWS
? TEMPERATURE RATING 125°C
ORDERING INFORMATION
203-2737-55-1102
23
